ขาย YAMAHA RX-V675

Amplifier Section

Channel
7.2

Rated Output Power (1kHz, 1ch driven)
150W (4ohms, 0.9% THD [European Model])

Rated Output Power (20Hz-20kHz, 2ch driven)
90W (8ohms, 0.09% THD)

Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)
150W (8ohms, 10% THD)

Dynamic Power per Channel (8/6/4/2 ohms)
130/170/200/240W

Surround Sound Processing

CINEMA DSP
Yes (3D)

DSP Programs
17

Dialog Level Adjustment
Yes

Virtual Presence Speaker
Yes

Dialogue Lift
Yes (no presence speakers required)

SILENT CINEMA / Virtual CINEMA DSP
Yes

Dolby TrueHD
Yes

Dolby Digital Plus
Yes

Dolby Pro Logic IIx
Yes

DTS-HD Master Audio
Yes

Audio Features

Pure Direct
Yes (with video on mode)

Compressed Music Enhancer
Yes

YPAO sound optimization
Yes (R.S.C)

Adaptive DRC (Dynamic Range Control)
Yes

Initial Volume & Maximum Volume Setting
Yes

Bi-amp capability
Yes

Audio Delay
Yes (0-500 ms)

192kHz/24-bit DACs for all channels
Yes (Burr-Brown)

Video Features

4K Ultra HD Pass-through 6 upscaling
Yes

HDMI 3D passthrough
Yes

HDMI Audio Return Channel
Yes

HDMI upscaling
Yes (Analogue to HDMI / HDMI to HDMI)

Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync
Yes

Connectivity

HDMI Input/Output
6 (front 1) / 1

HDMI CEC
Yes (SCENE, Device Control)

MHL Support
Yes

USB Input
iPod/iPhone/iPad, USB Memory, Portable Audio Player

Network Port
Yes

AirPlay
Yes

Front AV Input
HDMI (MHL support)/USB/Composite

DC Out
Yes

Digital Audio Input/Output: Optical
2 / 0

Digital Audio Input/Output: Coaxial
2 / 0

Analog Audio Input/Output
4 / 1

Component Video Input/Output
2 / 1

Composite Video Input/Output
5 (front 1) / 1

Preout
SW (2 x mono)

Headphone Output
1

Tuner Section

FM/AM Tuner
Yes

User Interface

On-screen display
Graphical User Interface

SCENE
SCENE (4 sets)

App Control
Yes (iPhone/iPad/Android phone/tablet)

Web Browser Control
Yes

Remote Control Unit
Yes (Preset, Learning)

Zone Control

Zone 2 Audio Output
Line output

Powered Zone
Zone 2

+12V Trigger Output
1

Remote (IR) Input/Output
1 / 1

General

Standby Power Consumption (IR only)
≤0.15W

Auto Power Standby
Yes

ECO mode
Yes

Dimensions (W x H x D)
435 x 171 x 364 mm; 17-1/8” x 6-3/4” x 14-3/8”

Weight
10 kg; 22.1 lbs.

7-channel powerful surround sound
150W per Channel (4 ohms, 1 kHz, 0.9 % THD, 1 ch driven [European Model])
90W per Channel (8 ohms, 20 Hz-20 kHz, 0.09 % THD, 2 ch driven
150W per Channel (8 ohms, 1 kHz, 10 % THD, 1 ch driven, JEITA)
Discrete amp configuration
MHL supports full HD video and audio from mobile phones and portable devices
Network functions such as AirPlay, Napster®* music streaming service and AV Controller app
*Music service availability varies by region.
High quality video processing with precise deinterlacing
YPAO Reflected Sound Control (R.S.C.) sound optimisation for automatic speaker setup
HDMI (6 in/1 out) with 4K upscaling, 3D and Audio Return Channel
HDMI input and USB terminal on front panel
FLAC or WAV 192kHz/24-bit audio playback
Advanced multi-language GUI on-screen display with (English, German, French, Spanish, Russian, Italian, Japanese and Chinese)
Dialogue Lift and Dialogue Level Adjustment for natural dialogue and vocals
Versatile Zone control such as Zone 2 on/off and control on front panel
ECO mode operation for about 20% less power consumption
