เครื่องวัดก๊าซคาร์บอนไดออกไซด์
Carbon Dioxide CO2 Meter ZG106
is a portable, accurate handheld CO2 Monitor, which can be put on desktop also, to measure the CO2 concentration and ambient temperature. Used NDIR technology to improve the long term stability. Build-in several modes help you understand ambient air guality.
Features :
Ultra low cost CO2 Monitor achieved by New IR-SoC Technology .
It uses NDIR technology to improve the long term stability.
Portable, accurate handheld CO2 Monitor.
The Alarm mode will sound at 1000 PPM or adjust the alarm level
Max/Min mode
SPECIFICATIONS
Method - NDIR
Display - LCD
Independent CO2 and Temperature readings.
Calculates and Displays Ventilation Rates
Sample Method - Diffusion or flow through (50 ~200 ml/min)
Performance - CO2
ZG 106
Measurement Range 0~3,000ppm
Resolution 1ppm at 0~1,000ppm;
5ppm at 1,001~2,000ppm;
10ppm at 2,001~3,000ppm
Accuracy ±50 ppm or ±5% of reading
Repeatability ±20 ppm
Temperature Dependence ±0.1% of reading per °C or ±2 ppm per °C, whichever is greater, referenced to 25°C
Pressure Dependence 0.13% of reading per mm Hg (Corrected via user input for altitude)
Response Time
Warm-Up Time
Performance - Temperature
Temperature Range Display 32 to 122°F (0 to 50°C)
Display Resolution 0.1°F (0.1°C)
Display Options °F / °C, or Off. Set with Up / Down button
Accuracy ±2°F (±1°C)
Response Time 20-30 minutes (case must equilibrate with environment)
Outputs
OC: Normally Low,100mA max. @ 24VDC. Adjustable setpoint, factory setting is 1000ppm,hysteresis is 50ppm
One RJ-45 Connector digital output in RII protocol.
One Graphing Software ZyAura® View (Under developing)
Power Supply
Two power supply types
Battery type: Alkaline, AA* 4 (80 hours)
External: 6 VDC from external AC/DC adapter which is included in package(Use specified AC adapter only)
Power Requirement 160 mA Peak, 15 mA average from 6V
General Operating Conditions
Operating Temperature: 32-122°F (0-50°C) 0-95% RH, non-condensing
Storage Temperature: -4 to 140°F (-20 to 60°C)
Dimensions：24.3×81.1×165 mm (0.96×3.19×6.50 inch)
Weight (including batteries)：273.6 grams(9.65 oz)
