เครื่องวัดสายสัญญาณ MT-8200-50A
Fluke Networks MT-8200-50A IntelliTone 100 Kit
Features:
Digital cable-sensing toner and probe for identifying cables in bundled voice, data, and video installations
Safely and effectively traces cables hidden in floors, ceilings, walls, and elsewhere--even on active networks
Decisively rejects noise and false signals while correctly isolating coaxial and bare wires
Diagnoses and troubleshoots telecom/data services; visual and audible signal strength indicators
Toner measures 2.94 x 5.54 x 1.2 inches (W x H x D); probe measures 8.73 x 1.88 x 1.26 inches
Digital and analog tone generator and probe kit locates and traces data cabling on active networks and voice, audio, and video cabling on inactive networks
Identifies the type of service and tests for voltage, polarity, ring, and continuity
F-type connector supports VDV cable types including RJ45, RJ11, coaxial, and bare wire, and banana jacks accommodate test leads
Four distinct cadences for isolating individual wire pairs
Kit includes RJ11-to-RJ11 and RJ45-to-RJ45 patch cords, a test lead set with banana jacks to alligator clips, a female-to-female F-type connector adapter, a 9V alkaline battery, a product manuals CD, and instructions
GENERAL SPECS
Operating temperature
32 °F to 104 °F (0 °C to 40 °C)
Storage temperature
-4 °F to +140°F (-20 °C to °C)
Operating relative humidity (% RH without condensation)
95 % (50 °F to 95 °F; 10 oC to 35 °C)
75 % (95 °F to 104 °F; 35 °C to 40 °C) Uncontrolled < 50 °F (< 10 °C)
Vibration
Random, 2 g, 5 Hz-500 Hz
Shock
1 m drop test with and without module
Safety
EN 61010-1 1st Edition Amendments 1, 2
Altitude
3000 m
EMC
EN 61326-1
Battery type and life
9 V alkaline (NEDA 1604A or IEC 6LR61); 20 hours typical
Applications
Copper cabling media including; 75 or 50 Ohm Coaxial cable; Two Conductor control, security, generic cabling. 10 Base-T or 10/100 Base-T datacom networks. POTS telecom service and UTP cable. Shielded Twisted Pair supported in Cablemap function of the IntelliTone 200.
TONER SPECS
Dimensions 5.54 in x 2.94 in x 1.25 in (14.1 cm x 7.5 cm x 3.2 cm)
Display LED
Control Thumbwheel switch
Toner interface Main Mod8 port for tone generation on all 4 pairs of UTP / STP cabling. F Connector for coaxial cabling Banana Jack Plugs (2) - two conductor wiring
Toner frequency IntelliTone™ signal: encoded digital signal
Analog SmartTone signal: 500 - 1200Hz, 4 songs
Talk battery voltage 6 V into 600 W
Ouptut power 5 V p-p
Voltage protection 100V
Auto power down Turns off automatically after 2 1/2 hours of inactivity
PROBE SPECS
Dimensions 8.73 in x 1.88 in x 1.26 in (22.2 cm x 4.8 cm x 3.2 cm)
Display (8) LED indicators, Synch LED indicator
Audio IntelliTone: Microprocessor controlled audio files
Analog: Detected toner signal
Control Thumbwheel switch, volume control wheel
Tone detection Detects IntelliTone™ digital signal for Locate, Isolate, and CableMap
Detects analog SmartTone signal (500-1200Hz) and other analog toners.
Toner interface Main Mod8 port for cablemap on all 4 pairs of UTP / STP cabling.
Auto power down Turns off automatically after 1 hour of inactivity
