Dimensions (H x W x D)
✓ 1510 x 760 x 670 mm
Weight
✓ 110 kg
Hypoxic guard system
✓ Total flow range: 0–20 L/min
Vaporizers
✓ Backbar for two Selectatec vaporizers (German or British standard) with interlock safety mechanism
Integrated breathing system (IBS)
✓ Hanging Insp./Exp. valve flaps
✓ Tool-free disassembly in less than sixty seconds
✓ Fresh gas introduced after Insp. valve
Absorber capacity
✓ 900 g
Ventilation modes
✓ VCV (volume-controlled ventilation)
✓ PCV (pressure-controlled ventilation)
✓ SIMV (synchronized intermittent mandatory ventilation)
✓ PSV (pressure support ventilation)
✓ PRVT* (pressure-regulated volume target)
✓ Manual, spontaneous
Tidal volume
✓ 20 to 1500 ml
Respiration rate
✓ 4 to 80 bpm
I:E ratio
✓ 3:1 to 1:9,9
Electronic PEEP
✓ 4 to 20 hPa (cmH2O)
Inspiratory pressure
✓ PCV 4 to 67 hPa (cmH2O)
✓ PSV 4 to 50 hPa (cmH2O)
AGS System
✓ 30 to 40 L/min
Ventilation measurements
✓ Peak, Plateau, and PEEP Pressure
✓ Patient compliance
✓ Tidal & minute volume
✓ Inspired O2%*
✓ Spirometry loop*
