Main Features
- Linear Motor Drive System
Linear motor drive system is the most ideal mechanism which semi-permanently sustains high-speed axis-movements and instantaneous response. With 10-years of history providing linear motor-driven machines, Sodick offers 10-years of positioning accuracy guarantee on its linear motors for the first time ever in EDM industry.
- New Generator
The 5th generation electrical discharge technology has adopted the "Perfect Active Control," enabling simultaneous control of high-speed electrical discharge and axis-movements by using serial communication technology of 1Gbit/sec.
- Arc-less & High Quality Surface Finish
The new "Arc-less" electrical discharge system features further improved in machining performance, and ensures great reduction in machining time. Equipped with "SVC" circuit as standard, high-quality surface finishing, satin surface, and mirror surface can be achieved with great ease.
Specification
X,Y,Z axis stroke (mm) 850 × 520 × 420
Max. suspended weight (kg) 100
Max. weight of workpiece (kg) 3000
Machine tool dimensions
(Width × Depth × Height) (mm) 2060 × 3130 × 2900
（includes power supply）
（includes power supply and dielectric tank）
