| Output |
5HP(3.7 kW), 7.5HP(5.5 kW), 10HP(7.5 kW) |
| Pole |
4 |
| Phase |
3 phase |
| Voltage/Frequency |
LT: 220/380 ̴ 415V 50Hz, 220/440V 60Hz HT: 3802 ̴ 440V 60Hz |
| Gear Ratio |
1/3 ̴ 1/60 (7.5HP : 1/3 ̴ 1/30) |
| Rating |
S1 (continuous) |
| Insulution Class |
F (155˚ C) |
| Casting Construction |
Totally-enclosed fan-cooled |
| Protective Construction |
Output (IP55) |
| Mounting |
Foot mount |
| Frame Material |
Steel |
| Mounting Direction |
Grease lubrication type : Universal direction/ Oil lubraication type : Limited (see page 4) |
| Ambient Temperature |
15 ̴+40˚ C (No freezing) |
| Ambient Humidity |
90% RH or less |
| Elevation |
up to 1,00 meters above sea level |
| Vibration |
4.9m/s² or less constantly, 9.8m/s² or less instaneously |
| Lubrication |
5HP (1/3 ̴ 1/30) : Grease lubrication (Pyroknock Universal#000) |
| Lubrication |
5HP (1/40 ̴ 1/60), 7.5, 10HP : Oil lubraication (no filled oil from factory) |
| Service Factor |
1.4 (reduction gear) |
| Conformative Standard |
IEC 60034-1, JEC-2137-2000 |
| Paint |
Munsell N5.5 (gray) |
| Accessories |
Shaft end key (JIS B 1301-1996) |
