GENERAL
Packaged Quantity 1
Product Type Digital camera - mirrorless system
Enclosure Color white, black
Sensor Resolution 12.3 Megapixel
Optical Sensor Type High speed Live MOS
Total Pixels 13,100,000 pixels pixels
Effective Sensor Resolution 12,300,000 pixels pixels
Optical Sensor Size 13.0 x 17.3mm
Field of View Crop Factor 2
Sensor Dust Reduction Yes
Sensor Features Supersonic Wave Filter (SWF)
Optical Zoom 3 x
Image Processor TruePic V
Image Stabilizer optical (image sensor shift mechanism)
Auto Focus TTL contrast detection
Auto Focus Points (Zones) Qty 225
Digital Video Format AVI, MJPEG
Image Recording Format JPEG, RAW, RAW + JPEG
Max Video Resolution 1280 x 720
AV Interfaces HDMI, USB 2.0, composite video/audio
Print Standard Direct print, DPOF support, PictBridge support, PRINT Image Matching
Interfaces Provided Composite video/audio, HDMI, USB 2.0
ISO (Max) 3200
ManufacturerOlympus
EXPOSURE & WHITE BALANCE
Light Sensitivity ISO 100-3200, ISO auto (200-1600)
Exposure Metering center-weighted, multi-segment, spot
Exposure Metering Zones 324
Exposure Modes aperture-priority, automatic, bulb, manual, program, shutter-priority
Shooting Programs anti shake, macro, nature macro, night scene, night scene with portrait, panorama assist, portrait mode, sports mode, sunset, beach/snow, children, documents, e-portrait, fireworks, high key, landscape, low key
Special Effects Black & White Blue filter, Monotone, Muted, Natural, Pin Hole, Pop Art, Portrait, Sepia, Soft Focus, Vivid, i-Enhance, Black & White Green filter, Black & White Magenta filter, Black & White Orange filter, Black & White Red filter, Black & White Yellow filter, Diorama, Gentle Sepia, Grainy Film
White Balance automatic, custom, presets
White Balance Presets 2000K - 14000K, daylight, flash, fluorescent light (cool white), fluorescent light (daylight), fluorescent light (warm white), overcast, shade, tungsten light
Max Shutter Speed 1/4000 sec
Min Shutter Speed 60 sec
Exposure Compensation ±3 EV range, in 1, 1/2 or 1/3 EV steps
Auto Exposure Bracketing 3 steps in 1/3, 1/2, 2/3, 1 EV steps
White Balance Bracketing Yes
X-sync Speed 1/180 sec, 1/2000 sec
Exposure Range EV 0-18 (ISO 100)
LENS SYSTEM
Type 3 x zoom lens - 14 - 42 mm - f/3.5-5.6 Micro Four Thirds
Focal Length Equivalent to 35mm Camera 28 - 84mm m
Focus Adjustment automatic
Min Focus Range 9.8 in
Max View Angle 75 degrees
Zoom Adjustment manual
Lens Construction 8 groups / 9 elements
Filter Size 40.5 mm
Lens System Mounting Micro Four Thirds
Features ED glass, aspherical lens
Lens Mounting Type Micro Four Thirds
LENS SYSTEM (2ND)
Type 3.8 x zoom lens - 40 - 150 mm - f/4.0-5.6 Four Thirds
Focal Length Equivalent to 35mm Camera 80 - 300mm
Min Focus Range 35.4 in
Focus Adjustment automatic, manual
Lens Construction 9 groups / 12 elements
Filter Size 58 mm
Features ED glass, internal focusing system
CAMERA FLASH
Camera Flash pop-up flash
Guide Number (m / ISO 100) 7
Flash Modes auto mode, fill-in mode, flash OFF mode, rear curtain sync, red-eye reduction, slow synchro
Features flash +/- compensation, wireless off-camera control
ADDITIONAL FEATURES
Continuous Shooting Speed 3 frames per second
Self Timer Delay 12 sec, 2 sec
Flash Terminal hot shoe
Additional Features 720p HD movie recording, built-in speaker, camera orientation detection, cropping an image, digital image rotation, digital noise reduction, face detection, highlight point display, histogram display, in-camera red-eye fix, resizing an image, AE lock, saturation control, shadow point display, sharpness control, sharpness control, histogram display, in-camera red-eye fix, resizing an image, saturation control, shadow point display, sharpness control, AF lock, sharpness control, Full-time Live View, RGB primary color filter, Scene Detection Technology, Shadow Adjustment Technology, audio recording, built-in help guide, audio recording
DISPLAY
Type 2.7" LCD display
Resolution 230,000 pixels
Display Features built-in
MICROPHONE
Microphone Operation Mode mono
CONNECTIONS
Connector Type 1 x USB 2.0
1 x composite video output
1 x HDMI output
Memory Card Slot SD card
SOFTWARE
Software Drivers & Utilities, [ib] software
SYSTEM REQUIREMENTS FOR PC CONNECTION
Operating System Support MS Windows 7, MS Windows Vista, MS Windows XP SP2 or later
Peripheral Devices CD-ROM drive, USB port
MISCELLANEOUS
Microsoft Certifications Compatible with Windows 7
Included Accessories USB cable, battery charger, body cap, dust cap, shoulder strap, video cable, lens adapter, lens cap, shoulder strap, video cable
Body Material aluminum, plastic
BATTERY
Battery Type Olympus BLS-1
Details 1 x Li-ion rechargeable battery - 1150 mAh (included)
MEMORY / STORAGE
Memory Card Slot SD card
Supported Memory Cards SD Memory Card, SDHC Memory Card
Image Storage RAW 4032 x 3024
JPEG 4032 x 3024
JPEG 2560 x 1920
JPEG 1600 x 1200
JPEG 1280 x 960
JPEG 1024 x 768
JPEG 640 x 480
Video Capture AVI - 1280 x 720 - 30 fps
AVI - 640 x 480 - 30 fps
DIMENSIONS & WEIGHT
Width 4.8 in
Depth 1.4 in
Height 2.8 in
Weight 10.6 oz
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
GENERAL
ManufacturerOlympus
